Proel HPC210BK
Kód: HPC210BKm
Mikrofonní kabel mentráž
Proel HPC210BK
Uvedená cena za 1 metr.
Application fields: Recording studios Microphone connections
Conductors: Bare copper 24 AWG = 30 x 0.10 mm (0.22 mm²)
Insulation: Superflexible PVC HT105 ø 1.60 mm
Display: CONDUCTORS Spiral cotton filler CABLE Spiral copper 16x5x0.10 mm > 90%
Jacket: Flexible PVC 60 shore ø 6.50 mm
Conductor resistance: 93 Ohm/Km @ 20°C
Shied resistance: 20 Ohm/Km @ 20°C
Conductor/conductor capacitance: 46 pF/mt @ 1 KHz
Conductor/shield capacitance: 90 pF/mt @ 1 KHz
Velocity of propagation: 80 %
Operating temperature: -20°C / +70°C
Working voltage: 50 V
Minumum bendig radius: 20x cable section radius
Weight: 46 Kg/Km
Colours Available: Black
